Takeoff Weight |
<249 g
* Standard drone weight (with Intelligent Flight Battery, propellers and microSD card). Actual product weight may vary due to differences in batch materials and external factors. Registration is not required in some countries and regions. Check local rules and regulations before use. These specifications have been determined through tests conducted with the latest firmware. Firmware updates can enhance performance, so updating to the latest firmware is highly recommended.
|
Dimensions (L×W×H) |
Folded (without propellers):
Length: 145 mm, width: 90 mm, height: 62 mm
Folded:
Length: 171 mm, width: 245 mm, height: 62 mm
Folded (with propellers):
Length: 251 mm, width: 362 mm, height: 70 mm
|
Diagonal size |
247 mm
|
Max Ascent Speed |
5 m/s (S mode)
3 m/s (N mode)
2 m/s (C mode)
|
Max Descent Speed |
5 m/s (S mode)
3 m/s (N mode)
1.5 m/s (C mode)
|
Max Speed (at sea level, no wind) [2] |
16 m/s (S mode)
10 m/s (N mode)
6 m/s (C mode)
* Max. flight speed is subject to local restrictions that may change. Please abide by local laws and regulations when flying.
|
Max Service Ceiling Above Sea Level |
With Intelligent Flight Battery: 4000 m
With Intelligent Flight Battery Plus: 3000 m
* Increasing drone weight may affect the drone's propulsion system. When the aircraft is using the Intelligent Flight Battery Plus, do not mount additional payloads like a propeller guard or third-party accessories to avoid a lack of propulsion.
|
Max Flight Time |
34 min. (with Intelligent Flight Battery and flying at 21.6 km/h in windless conditions)
47 min. (with Intelligent Flight Battery Plus and flying at 21.6 km/h in windless conditions)
|
Max Hovering Time |
30 min. (with Intelligent Flight Battery in windless conditions)
40 min. (with Intelligent Flight Battery Plus in windless conditions)
|
Max Flight Distance |
18 km (with Intelligent Flight Battery when flying at 43.2 km/h in windless conditions)
25 km (with Intelligent Flight Battery Plus when flying at 43.2 km/h in windless conditions)
|
Max Wind Speed Resistance |
8,5–10,5 m/s (Level 5)
|
Max Tilt Angle |
Front: 40°, rear 35° (S mode)
25° (N mode)
25° (C mode)
|
Max Angular Velocity (by default)* |
130°/s (Mode S)
* Can be adjusted from 20°/s to 250°/s in the application
75°/s (Mode N)
* Can be adjusted from 20°/s to 120°/s in the application
30°/s (Mode C)
* Can be adjusted from 20°/s to 60°/s in the application
|
Global Navigation Satellite System (GNSS) |
GPS + Galileo + BeiDou
|
Hovering Accuracy Range |
Vertical:
±0.1 m (visual positioning)
±0.5 m (satellite positioning)
Horizontal:
±0.3 m (visual positioning)
±1.0 m (high-precision positioning system)
|
Forward |
Accurate measurement range: 0.39-25 m
Obstacle detection speed:
Flight speed <10 m/s
Viewing angle: 106° (horizontal plane),
90° (vertical plane)
|
Backward |
Accurate measurement range: 0.36-23.4 m
Obstacle detection speed:
Flight speed <10 m/s
Viewing angle: 58° (horizontal plane),
73° (vertical plane)
|
Downward |
ToF measurement range:
0.1-8 m
Fine positioning range: 0.5-12 m
Video sensor positioning range: 0.5-30 m
|
Optional bottom light |
No
|
Operating Environment |
Non-reflective distinguishable surfaces
with clear texture and diffuse reflection >20%
(e.g. cement coating)
Adequate illumination
(>15 lux, normal fluorescent lighting)
|
Mechanical range of rotation angles |
Tilt: -135°…80°
Roll: -135°…45°
Pivot: -30°…30°
|
Operating range of rotation angles |
Tilt: -90°…60°
|
Stabilization |
3-axis mechanical stabilization (tilt, roll, swivel)
|
Max Control Speed (tilt) |
100°/s
|
Angular vibration range |
±0,01°
|
Supported Memory Cards |
UHS-I Speed Class 3 or above is required. A list of recommended microSD cards can be found below.
|
Transmitter power(EIIM) |
2.400-2.4835 GHz:
<26 dBm (FCC),
<20 dBm (CE/SRRC/MIC)
|
Max sizecompatiblemobile device |
Length: 180 mm, Width: 86 mm, Height: 10 mm
|
Supported connector types |
Lightning, Micro USB (Type-B), USB-C
|
Matrix |
CMOS 1/1.3-inch
Number of effective pixels: 48 megapixels
|
Lens |
Angle of view: 82.1°
24 mm format equivalent
Aperture: f/1.7
Focus: 1 m to ∞
|
ISO Range |
Video:
100-6400 (auto)
100-6400 (manual setting)
Photo:
100-6400 (auto)
100-6400 (manual setting)
|
Shutter speed |
Electronic shutter speed: 2-1/8000 с
|
Max Image Size |
4:3:
8064×6048 (48MP)
4032×3024 (12MP)
16:9: 4032×2268 (12 MP)
|
Still Photography Modes |
Frame-by-frame
Interval:
JPEG: 2/3/5/7/10/15/15/20/30/60 s
JPEG + RAW: 2/3/5/7/10/15/15/20/30/30/60 s
Auto Exposure Bracketing (AEB):
3/5/7 exposure steps in 2/3 EV increments
Panorama:
you can choose spherical panorama, 180°,
wide-angle or vertical format.
|
Photo format |
JPEG/DNG (RAW)
|
Video Resolution |
4K: 3840×2160 at 24/25/30/48/50/60 fps
2.7K: 2720×1530 at 24/25/30/48/50/60 fps
FHD: 1920×1080 at 24/25/30/48/50/60 fps
Slow motion: 1920×1080 at 120 fps
|
Video format |
MP4/MOV (H.264/H.265)
|
Magnification range |
4K: 2x
2.7K: 3x
FHD: 4x
|
Quick Shooting Modes |
Droni, Circle, Spiral, Rocket, Boomerang and Asteroid
|
Color profiles |
Regular
D-Cinelike
|
Supported file systems |
FAT32 (≤32 GB)
exFAT (>32 GB)
|
Broadcast quality |
1080p/30 fps
|
Operation Frequency |
2.400-2.4835 GHz
According to local laws, the 5.8 GHz frequency is prohibited in some countries, such as Russia, Japan, Israel, Ukraine and Kazakhstan. Please use the 2.4 GHz frequency band when operating in these locations. Always check local rules and regulations before use, as they may change over time.
|
Communication bandwidth |
1.4 MHz ⁄ 3 MHz ⁄ 10 MHz ⁄ 20 MHz ⁄ 40 MHz
|
Signal delay (depends on site conditions and mobile device) |
Drone + remote control: About 120 m/s
|
Max Video Bitrate |
Aircraft + Remote Controller: 18 Mbps
|
Max Download Bitrate |
DJI O3:
DJI RC-N1 remote control 5.5 MB/s
DJI RC: 5.5 MB/s
Wi-Fi 5:
Max. 30 Mbytes/s
* Measured under lab conditions with minor interference in countries/regions supporting both 2.4 GHz and 5.8 GHz. With footage saved on an SD card or the internal storage. Download speeds may vary depending on actual conditions.
|
Signal Transmission Ranges (FCC) [6] |
Severe interference (urban areas): About 1-3 km
Medium interference (suburban areas): About 6 km
Low interference (suburban/coastal areas): About 12 km
*Measurements obtained in an open environment with no interference while meeting the FCC standard. Only to serve as a reference and provides no guarantee as to the actual flight distance.
* Maximum one-way communication distance of DJI Mini 3 Pro in countries/regions with different standards:
FCC:
USA, Australia, Canada, Hong Kong, Taiwan, Chile, Columbia, Puerto Rico and other regions.
Max signal transmission range 12 km
SRRC:
Mainland China.
Max. signal transmission range: 6 km
CE:
United Kingdom, Russia, France, Germany, Portugal, Spain, Switzerland, Macau, New Zealand, UAE and other regions.
Max. signal transmission range 6 km
MIC:
Japan.
Max. transmission range: 8 km
|
Antennas |
2T4R with 4 antennas
|
Audio transmission |
No
|
Weight |
80,5 г
|
Capacity |
3850 mAh
|
Voltage |
7,38 В
|
Charging voltage limit |
8,5 В
|
Battery type |
Lithium-polymer 2S
|
Energy |
28.4 W/h.
|
Max charging power |
58 W
|
Charging time |
101 min. (when using a 30 W charger)
|
Charging temperature range |
From +5° to +40°C
|
Recommended charger |
DJI 30W USB-C Charger
or a device that supports USB power transfer protocol
|
Model |
RM330
|
Video transmission system |
DJI O3
|
Transmitter Power (EIIM) |
2.400-2.4835 GHz:
2.400-2.4835 GHz:
< 26 dBm (FCC),
<20 dBm (CE/SRRC/MIC)
|
Memory capacity |
The DJI RC's memory capacity can be expanded using a microSD card.
Users can save images and videos to the
memory card and export them to a computer or other devices.
|
Video output port |
No
|
Max Battery Life |
Approx. 4 hours
|
Operating temperature range |
From -10 to +40°C
|
Recommended microSD Cards |
SanDisk Ultra A1 U1 16GB
SanDisk Extreme U3 16GB
SanDisk Ultra A1 U1 32GB
SanDisk Extreme A1 U3 32GB
Kingston A2 V30 U3 64GB
SanDisk Extreme A2 V30 U3 64GB
SanDisk Extreme Pro A2 V30 U3 64GB
SanDisk High Endurance V30 U3 64 GB
Kingston A2 V30 U3 128 GB
SanDisk Extreme A2 V30 U3 128 GB
SanDisk Ultra A1 U1 200 GB
Kingston A2 V30 U3 256 GB
SanDisk Extreme A2 V30 U3 256 GB
SanDisk Extreme PRO A2 V30 U3 256 GB
SanDisk Extreme A2 V30 U3 512 GB
|
Protocol |
802.11 a⁄b⁄g⁄n
|
Powertransmitter(EIIM) |
2.400-2.4835 GHz: <23 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.150-5.250 GHz: <23 dBm (FCC/CE/SRRC/MIC)
|
Compatible DJI charger |
DJI 30W USB-C Charger
or other device that supports USB power transfer protocol
|
Compatible DJI Batteries |
Intelligent Flight Battery DJI Mini 3 Pro,
Intelligent Battery Plus DJI Mini 3 Pro battery
|
Input |
5 V, 3 A
9 V, 3 A
12 V, 3 A
|
Output (USB) |
Max Voltage: 5 V, Current: 2 A
|
Charging type |
Three batteries are charged in series
|
Mobile device app |
DJI Fly
|
System Requirements |
iOS 11.0 and later versions
Android 6.0 and later versions
|
